Description
Overview Of CoCrMoW
CoCrMoW is a cobalt-chromium-molybdenum-tungsten alloy designed for high-performance applications requiring exceptional wear resistance, corrosion resistance, and thermal stability. Widely used in biomedical implants, aerospace components, and high-temperature tooling, this alloy combines the strength of cobalt with the hardening effects of chromium, molybdenum, and tungsten.
Powder Chemical Composition(wt,-%)
Typical composition of CoCrMoW powder (ASTM F75/F1537 standards):
| Element | Content (wt%) | Role |
| Cobalt (Co) | 55–65% | Base metal, provides high-temperature strength |
| Chromium (Cr) | 25–30% | Enhances corrosion and oxidation resistance |
| Molybdenum (Mo) | 5–7% | Improves strength, wear resistance, and grain refinement |
| Tungsten (W) | 3–5% | Increases hardness and thermal stability |
| Carbon (C) | ≤0.35% | Forms carbides for wear resistance |
| Nickel (Ni) | ≤1.0% | Optional for improved ductility |
| Iron (Fe) | ≤1.0% | Impurity control |
| Others (Si, Mn) | ≤1.0% | Trace elements |
Physical & Mechanical Properties
Key properties of CoCrMoW in as-sintered and heat-treated conditions:
| Property | As-Sintered | Heat-Treated |
| Tensile Strength (MPa) | 800–1000 | 1200–1500 |
| Yield Strength (MPa) | 600–800 | 900–1100 |
| Elongation at Break (%) | 8–12 | 5–8 |
| Hardness (HV) | 300–400 | 450–550 |
| Density (g/cm³) | 8.3–8.5 | 8.3–8.5 |
| Melting Point (°C) | 1350–1450 | 1350–1450 |
| Thermal Conductivity (W/m·K) | 12–15 | 12–15 |
| Corrosion Resistance | Excellent (passive oxide layer Cr₂O₃) | Enhanced carbide formation |
Comparison With Similar Alloys
| Alloy | Key Strengths | Primary Use |
| CoCrMoW | High wear/heat resistance | Medical implants, aerospace |
| Ti-6Al-4V | Lightweight, biocompatible | Aerospace, biomedical |
| Inconel 718 | Superior high-temperature strength | Jet engines, turbines |
| 316L Stainless | Cost-effective corrosion resistance | General industrial |
Key Features
Biocompatibility
● Meets ISO 5832-12 and ASTM F75 standards for surgical implants (e.g., hip/knee replacements).
● Resists body fluid corrosion and minimizes metal ion release.
Wear & Fatigue Resistance
● Ideal for high-stress applications like turbine blades, cutting tools, and engine valves.
● Retains hardness at elevated temperatures (up to 800°C).
Additive Manufacturing (AM) Compatibility
● Suitable for laser powder bed fusion (LPBF) and electron beam melting (EBM).
Powder specifications
● Particle size: 15–45 μm (spherical morphology).
● Oxygen content: <0.1% (critical for minimizing brittleness).
Post-Processing
● Heat treatment (e.g., solution annealing, aging) optimizes carbide distribution for peak performance.
● Surface polishing achieves Ra <0.1 μm for medical devices.
Standards & Certifications
● ASTM F75: Standard for cobalt-chromium-molybdenum alloy castings.
● ISO 5832-12: Implants for surgery – wrought cobalt-chromium-molybdenum alloy.
● AMS 5385: Aerospace material specification for investment castings.
Note: For AM processes, powder flowability and packing density are critical to minimize porosity. CoCrMoW’s carbide-forming elements (Mo, W) require controlled thermal cycles to avoid cracking.
Contact us if you need further details or modifications!
Primary Applications
Medical
● Orthopedic implants, dental prosthetics, and surgical instruments.
Aerospace
● Turbine blades, combustion chamber liners, and rocket nozzles.
Industrial
● Dies, molds, and wear-resistant coatings for mining equipment.
Energy
● Nuclear reactor components and oil/gas valve parts.
